Both ATC systems are functionally available, for both APP and ACC services.
Major system, by its size and also capacity, is the system COMPASS Magnus, which is designed for areas with more flights. The compact system with a stable nub and high level of flexibility is the system COMPASS Easy.
.jpg)
COMPASS Magnus is a complete modular ATC system. Interfacing components are based on recognized standards allowing implementations in both partial and complete ATC system upgrades.
Up to now, the ATC solutions were designed to be implemented on large scale operations. However the "one size fits all" monster system approach doesn't meet the requirements of small or medium size ACC, APP and TWR sites. It is based on the most advanced technology, open architecture, demand features, HMI personalization, cost effectiveness and safety. Now ready for the new and future communication standards.
•User friendly customizable HMI developed by ATCOs for ATCOs.
• A rule-based ATM solution tuned by final users.
• Conflict detection and separation solution proposal
• Backup possibilities
• FDPS – complete "all-in one" system functionality including Flight Data Processing and offering various user output (paper and electronic strip, thirdparty systems interface).
• Info pages
• e-Strip – down and upstream sector coordination, modification and revisions highlighting, external coordination results
• Jeti – front-end HMI to the FDP system functions, IFR and VFR flights modification, error messages management (OLDI, AFTN, FDE), A/C performances and A/D information, FDR archiving
• Statistic functions
• Output for billing systems
• SDPS – Multi-plot processing method (150 msec processing time); 10 years of operation.
• Complete radar and video recording functionality
• Voice recording compatibility
• Multilateration inputs are able to be processed by SDPS
• ADS-C positional reports are able to be processed by SDPS
• Datalink gateway integration
• Safety Nets module integrated in accordance with Eurocontrol’s standards
• OLDI upgrade to SYSCO level is developed as standalone software module respecting OLDI standard. Easy Coordination, Transfer and Hand over functions are available in friendly way for both internal sector – sector and system – system data exchange. Results of System Supported Coordination are available to ATCO in labels and electronic strips.
• Industry standards compliant (ICAO, Eurocontrol).
• Supervision and continuous monitoring of system units and its connectivity.
• Pragmatic alternative system with high potential of meeting ANS’s specific needs.
• Flexible and powerful solution.
• SDPS is able to use multilateration inputs.
• SDPS is able to use ADS-C positional reports.
• OLDI with SYSCO level integrated.
• New trajectory calculation in accordance with FASTI group.
• Safety Nets functions.
• Flexible sectorisation.
• Experiences with integration of regional airports systems into this ACC system.
• Over 20 years of experiences in operational support in Europe.
.jpg)
Size and availability of this compact system makes it very flexible for installation and quick
integration to cover airspace fulfill ICAO requirements.
System is re-build over the used one and stabile regional airport system. As major database is used Informix and it makes this system available for contingency functions where are different technologies and databases. Capabilities are basically oriented for smaller ACC or regular APP and TWR services. System is well documented and also safety assessment is applicable. Transformation from this size of the system to bigger one is possible with exchanges of FDPS and intern structure of the whole system. For Users there is a similar intuitive organization of control panel and the same CWS. The usage of Safety Nets is only the decision of the customer, because the system is possible to use and operate with Safety Nets module very effectively (see more on ATC modules). Architecture of the system is designed to ensure high reliability of the system even when functionality of one element is lost. That is why main system servers and in accordance of safety analyzes critical modules are in dual mode.
