Air curtains

We would like to present to you our wide range of air curtains, which thanks to their high-quality design, complete regulation, wide range of air and heating outputs, can be utilised for many different applications and provide our customers with the desired effect – energy savings.

All new products brought to the market (and gradually also the current products), are tested and certified by TÜV SÜD. Thanks to these processes all the requirements of EU legislation are met, with an emphasis on safety, health and environmental protection. Certified by QMS is not only permanent added value but also proof of the highest quality and a guarantee for our current and future business partners.

• Basic

• Comfort

• Design

• Industry

1. Basic

ECONOMIC-A Basic

This new air curtain which completes the line of basic air curtains is particularly unique due to the different design and the new technology elements applied. It is mainly designed for smaller shops, restaurants and entrances to administration buildings and similar.

In comparison with other air curtains in its class, the ECONOMIC-A Basic curtain uses a discharge jet pipe which ensures higher air power and the optimal spread of the air curtain profile.

SPECIFICATION
	Air curtain lengths: 0.6m; 0.9 m; 1.2 m and 1.8 m
	Range of use for door height up to 3 m
	Air flow up to 2100 m3/h
	Electrical and air-only version
	Remote control
	Exhaust jets provides excellent air flow
	Electrical heater up to 12 kW

ECONOMIC-B Basic

Offers an economical, efficient and compact solution of air curtain with the possibility of remote controller. This air curtain can be used to its full extent for doorways curtaining and also as an effective heating element. The air curtain is ideal for use in areas such as small shops, small storage areas, cold storage facilities, service facilities, bars entrance halls, offices etc.

	SPECIFICATION
	Air curtain lengths: 1.0 m, 1.5 m and 2.0 m
	Range of use for doors up to height of 4.5m with air flow output of up to 2 950 m3/h
	Two performance ranges of electric heaters with output of up to 18kW, or water heater up to 17.7kW
	remote controller
	3-level air output, 1 or 2 levels of heating output
	Adjustable lamellas on the exhaust allow effective direction of the air flow and maximum utilisation of the air curtain output

2.Comfort

STANDESSE Comfort ... NEW GENERATION

It is the new generation of the very successful comfort air curtain STANDESSE (VCS3).  Apart from the invigorated design, significant advances have been made in the area of new technologies and innovations. The most significant improvement is modular regulation via a – MODULE CONTROL SYSTEM with a wireless radio-frequency control option.  The unique construction design of the housing and exhaust enables very low noise levels of only 56.6 dB (A) even at the maximum air power output of 6300 m3/h! The new STANDESSE Comfort is offered in four sizes 1.0, 1.5, 2.0 and now in 2.5 m, in all power performance lines in standard configuration without heating, with electric and water heating. Easy maintenance and serviceability were considered during the development and construction of the air curtain.

	SPECIFICATION
	Length up to 2.5 m (1.0, 1.5, 2.0 and 2.5 m)
	Module control system – the same control system for all regulation systems SM, DM and DA
	Low noise level (mere 56.6 dB (A) at 6300 m3/h)
	Wireless radio-frequency control (DM, DA)
	3 power performance lines with a blow distance of up to 8.0 m and air volume of up to 6300 m3/h
	Water heating configuration (up to 72.1 kW), electric heating configuration (up to 24.5 kW) and without heating
	Simple maintenance and servicing
	Fresh and attractive design
	Plug & Play

VENESSE Comfort

VENESSE Comfort is manufactured an easy-to-use air curtain with new insulation technology that allows us to deliver the quietest operation even during high performance. The maximum acoustic pressure value at 3 m is 55 dB (A) when air output is 5500 m3/h. The air curtain’s height is 2.5 meters, and it is intended for doors as wide as 7.5 m. It is produced with an electrical filament heater in two performance versions (24 kW and 36 kW), as well as with water heater and air-only versions. The air curtain is equipped with an anchor stand that can be attached to either side of the air curtain for determining its installation position and connections. The air outlet is equipped with a composite system of easily adjustable lamellas that allow effective adjustment of air output direction. The water exchanger has two air release valves that also serve as draw-off valves to allow easy air release or purging. The air curtain is offered with electronic controls that can operate up to six curtains. In this mode, each air curtain reacts individually to the door switch that is connected to it. The VENESSE Comfort air curtain comes in standard white color (RAL 9010) or can be custom made in any RAL color, as well as stainless steel.

SPECIFICATION
	Electric heater, water heater and air-only versions
	Height: 2.5 m
	Air output up to 5500 m3/h
	Output for door widths up to 7.5 m
	Insulated cover, guaranteeing the quietest operation, 55 dB (A)
	Two-sided, left-right design
	Connects from the top or bottom
	Easily adjustable air lamellas
	Easy access through removable service cover
	Easy mounting on stand

STANDESSE Comfort

This air curtain has been designed with an emphasis on design and quality of manufacturing. Offers the maximum level of comfort of use together with complete electronic regulation and a wide range of designs. It’s most frequent use is in supermarkets, banks, hotels, restaurants, administrative buildings, shops, production halls, etc. The design of the air curtain ensures excellent curtaining effect, quiet running as well as easy installation and maintenance.

SPECIFICATION
	Air curtain lengths: 1.0 m, 1.5 m and 2.0 m
	4 output ranges with a range of uses for doors up to a height of 10.5 m with air flow output of up to 10 430 m3/h
	Water heater with an output of up to 62 kW, electric heater up to 18 kW or air only
	3-levels of air output, 2-levels of heat output or possibility of fully automatic mode in connection with up to three external switches
	Control of more several devices connected to one control panel at the same time
	A wide range of other accessories and hanging elements

FINESSE Comfort

This air curtain is intended for ceiling installation. The compact design of the air curtain allows easy mounting without need for extra parts or brackets. Maintenance is easy and the face grille is nice to look at while comprising the integrated intake and exhaust. The air curtain can be supplied with complete electronic regulation which allowing automatic running, which ensures maximum efficiency and a high level of energy savings. The most frequent use of this unit is in supermarket entrance halls, banks and hotels, restaurants and administrative buildings etc.

SPECIFICATION
	Air curtain lengths: 1.0 m, 1.5 m and 2.0 m
	2 output ranges with a range of uses for doors up to a height of 7.5 m with air flow output up to 5 040 m3/h
	Electric heater up to 18 kW, water heater up to 54.5 kW, air only version
	3-levels of air output, 2-levels of heating output or fully automatic mode in connection with up to three external switches
	A wide range of other accessories and hanging elements

OPTIMAL Comfort

OPTIMAL Comfort  air curtain represents economical advantageous solution of efficient air curtain which is offered with water heating, electric heating or without heating element. The air curtain can be supplied with power or electronic controller, which allows to chain 6 air curtains together. Using of new type of wire heating element saves up to 20% on electric energy.
The OPTIMAL Comfort air curtain is supplied with a simple control panel, which allows easy setting of the heating level and fan speed. When air curtains are chained, each one can be controlled by their respective door switches. The control panel can be used to set the cleaning interval of air curtain which is signalized on panel by a diode.
The OPTIMAL air curtain is offered as standard in white or in any other RAL color on request.

SPECIFICATION
	Air curtain length: 1.0 m, 1.5 m and 2.0 m
	For doors up to 6m with air flow output of up to 5600 m3/h
	Water heater with an output of 46 kW and electric heater with an output of up to 19 kW
	Exhaust jets for optimum utilization of air output
	Adjustable direction of exhaust
	Power and electronic control
	Chaining of up to 6 air curtains

3. Design

STYLESSE Design

Several changeable accessories are an innovation, which you alone can influence. It concerns, for example, magnetic trimmings on the sides,  changeable fluorescent lamps or types of scents. The air curtain is standardly supplied in metallic silver paint or any RAL colour according to requirements.  User friendly and intuitive control with a new design it easy for you to place and setup in the interior.

	SPECIFICATION
	single kapacity line, for opening heights of up to 5 m
	1.0 m; 1.5 m and 2.0 m lengths
	water heater and electric wire heater
	attractive design of the air curtain
	control panel with LCD display
	integrated PID heating control (with integrated antifreeze
	protection for water version)
	cartridge with fragrance
	36 months guarantee

INTENSSE Design

SPECIFICATION
	single kapacity line, for opening heights of up to 5 m
	1.0 m; 1.5mand 2.0mlengths
	water heater and electric wire heater
	attractive design of the air curtain
	control panel with LCD display
	integrated PID heating control (with integrated antifreeze
	protection for water version)
	available in version with germicide fluorescent lamp (UVC
	rays)
	cartridge with fragrance
	36 months guarantee

COMTESSE Design

New air curtain COMTESSE Design is to be predetermined to become a harmonious part of your interior. The fluorescent tube located on the body of air curtain highlight its lovely design. New type of wire heating element brings energy savings of up to 20%. One of new possibilities is to use the selectable individual modes of the air curtain when connecting a door switch. When air curtains are chained, each one can be controlled by their respective door switch.
The idea behind this type of controller was to provide maximum level of comfort and intuitive operating for the user. The LCD panel on the controller displays all important information. You can easily control the air curtain in manual mode or select automatic operation in the economical mode.
We offer COMTESSE Design  air curtains as standard in metallic silver or any other RAL color according to your request.

SPECIFICATION
	Air curtain lengths: 1.0 m, 1.5 m and 2.0 m
	Range of use for doors up to 6 m in height with volume of air flow up to 5600 m3/h
	Two output ranges of electric heater with outputs of up to 19 kW, water heater up to 46 kW
	Adjustable lamellas allow effective directing of air flow output and maximum utilisation of the air curtain output
	Water or electric version or without heating
	PID regulation of the electric heater - energy saving
	Wire heating element with minimum heat inertia
	Integrated water regulation
	Chaining of up to 6 air curtains
	New control panel with LCD display

4. Industry

INDESSE Industry

This is an air curtain designed for use in industrial areas and to curtain more exacting areas. It can be mounted horizontally or vertically. The design and output of the curtain was adapted to the usage in question. All this is reflected in long lifespan and reliability of the device, which thanks to this fact is maintenance-free and easy to operate. The air curtain is particularly used to curtain large openings such as doorways in production and storage halls, hangars, garages, machine plants and transport depots etc.

SPECIFICATION
	Individual modules are manufactured in lengths of 0.55 m, 1.5 m and 2.0 m
	Range of use for doors at a height/width of up to 7 m with an air volume of up to 10 200 m3/h
	Can be installed vertically or horizontally with easy connection of individual modules
	Electric heater up to 18 kW, water heater (2 output versions) up to 36 kW, or air only version
	5-level fan speed with the possibility to use external switches
	Control of several units at once using one control panel
	Possibility to supply sophisticated solution for regulation of water heating
